Sprinklers leveren een belangrijke bijdrage aan de brandveiligheid. Het Nederlands Instituut Publieke Veiligheid (NIPV) en de Verenigde Sprinkler Industrie (VSI) werken samen aan kennisontwikkeling. Voor de opleidingsdoeleinden is een vitrinekast met diverse sprinklerkoppen geplaatst. Via de QR code kom je meer te weten over de verschillende type sprinklerkoppen.
Bovenste plank voor:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 1-1 | VK598 | Opslag Upright Sprinkler (Storage-Specific Application) (K25.2) | |
| 1-2 | TY7151 | K17- 16.8 K-factor Up right, Standard Response, Standard Coverage | |
| 1-3 | RA1124 | K16.8 Upright Standard Response Storage and Non-Storage | |
| 1-4 | RA1914 | ESFR pendent K16.8 | |
| 1-5 | V4601 | K25.2 CMSA PENDENT 72°C STD RESP BRASS 1" BSPT | |
| 1-6 | TY6226 | ESFR-1 14.0 K-factor Pendent: ELEMENT VERWIJDERD |
Bovenste plank achter:
2e plank voor:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 2-1 | VK514 | ESFR VK514 Pendent Brass K28 7 | |
| 2-2 | VK503 | K17 ESFR 3/4" NPT Pendent Bras | |
| 2-3 | V4702 | K16.8 ESFR PEN 155F/68C QR BR 3/4 BSPT | |
| 2-4 | VK510 | K25 ESFR 1" BSP Pendent Brass | |
| 2-5 | R602 | ESFR,PENDENT,165,K25,1 | |
| 2-6 | RA0842 | EC PENDENT,74C,K25.1,BRASS BSPT | |
2e plank voor:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 3-1 | R1314 | pendent Quick-Response, Institutional Sprinklers. Standard | |
| 3-2 | TY3382 | 5.6K Institutional Sprinklers Horizontal Sidewall Quick Response, Extended Coverage | |
| 3-3 | R4514 | XL QR pendent Quick Response Pendent, Flush | |
| 3-4 | TY5151 | Upright and Pendent Sprinklers Standard Response, Standard Coverage | |
| 3-5 | VK530 | Sprinkler ELO 5mm 3/4" K=161 Upright Bra | |
| 3-6 | V3404 | K11,2 UP Brass | |
2e plank midden:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 4-1 | V1001 | K1.4 WINDOW SPRINKLER BRASS | |
| 4-2 | VK793 | Open Window Sprinkler Model C-1 180° 1/2 | |
| 4-3 | ? | brass K5.6 110 openingshoek | |
| 4-4 | TFP F822 | F834 MULSIFYRE Directional Spray Nozzles, Open, High Velocity | |
| 4-5 | D3 Directional Spray Nozzles, Open, TFP802 Appendix Material | ||
| 4-6 | TFP815 | High-Velocity Directional Spray Nozzles | |
| 4-7 | MV12T | MV-T Tank Top Medium Velocity Open Nozzles | |
2e plank achter:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 5-1 | R2921 | Storage and Non-Storage Sprinklers K11.2 met plaat | |
| 5-2 | TY315 | K5.6 Pendent, and Recessed Pendent Standard Response, Standard Coverage | |
| 5-3 | TY3231 | Poly-Stainless Sprinklers Pendent 5.6K, TY-FRB Quick Response | |
| 5-4 | RA6524 | Stainless Steel Sprinklers | |
3e plank voor:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 6-1 | V2740 | K4.9 RESIDENTIAL PENDENT SPRINKLER 155F/68C QUICK RESPONSE WHITE 1/2 NPT | |
| 6-2 | RA1414 | PENDENT,68C,1/2,BSPT CHROME N | |
| 6-3 | VK486 | Residential 1/2" horizont. Sidewall | |
| 6-4 | R3516 | PENDENT,155,K4.9,PLY WHITE N | |
| 6-5 | V2738 | K4.2 Res sidewall wit | |
| 6-6 | R3531 | H0RIZ0NTAL,155,K4.4,PLY WHITE N | |
| 6-7 | RA1425 | Intermediate Upright 5.6 brons | |
3e plank achter:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 7-1 | R401 | Concealed | |
| 7-2 | VK494 | K4.9 RES PD CD 155 LPCB | |
| 7-3 | V3802 | K5.6 CONCEALED 155F/68C QR BRASS 1/2 NPT | |
| 7-4 | VK4621 | K5.6 OR PD CD 68°C | |
| 7-5 | VK638 | concealed sidewall | |
| 7-6 | TFP420 | 4.2 K-factor Flush Pendent | |
4e plank voor:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 8-1 | VK3521 | 3/4" K115 QR SP CH 68C | |
| 8-2 | VK377 | Sprinkler 3mm 3/4" K=166 Pendent OR ELO BRAS | |
| 8-3 | V3702 | V3702 K8 Pen | |
| 8-4 | TY3189 | Combustible Concealed Space Sprinklers Specific Application, Upright | |
| 8-5 | RA4454 | KFR-CCS,212,UPRIGHT,5 6K,BRASS N | |
| 8-6 | TY6237 | 11.2 K and 14.0 K Pendent Extended Coverage Light and Ordinary Hazard | |
| 8-7 | GL1113 | K11.2 ECOH PENDENT SPRINKLER 155F/68C QUICK RESPONSE BRASS 3/4 NPT | |
4e plank achter:
| nummer | sin | beschrijving | |
|---|---|---|---|
| 9-1 | VK1001 | 1/2" K80 SR SU BR 141C | |
| 9-2 | RA1485 | Vertical Sidewall Sprinkler brons | |
| 9-3 | VK305 | Sprinkler 3mm 1/2" K=80 Ord. Hazard Hor. | |
| 9-4 | V2763 | K5.6 SPRINKLER PENDENT 155F/68C STANDARD RESPONSE CHROME PLATED 1/2" BSPT | |
| 9-5 | V2704 | K5.6 UPRIGHT 68C° QCK RESP BRASS 15MM BSP | |
| 9-6 | V2710 | K5.6 Side | |
| 9-7 | RA1435 | HORIZ0NTAL,68C,1/2 BSPT,CHROME N | |
Bodem
| nummer | sin | beschrijving | |
|---|---|---|---|
| 10-1 | V3408 | K11.2 PENDENT 68C QR BRASS 3/4 IGS met groefkoppeling V9 | |
| 10-2 | VK1550 | SDP SR 68C CR L200mm | |
| 10-3 | R5314 | F3,DRY,P,REC,155,WHITE,A 4 1/2 MTO K5.6 | |
| 10-4 | R5714 | F3QR,DRY,P,68C,BSPT,CHR0ME,A 8 1/2 MTO K5.6 | |
| 10-5 | V4804 | K25.2 ESFR SPRINKLER PENDENT 165F/74C QUICK RESPONSE BRASS W/ 1" IGS V9 COUPLING | |
| 10-6 | TY3255 | DS-1 – 5.6 K-factor, Dry-type Pendent, Standard Response, Standard Coverage | |
